Features / Specifications
Speaker type - 2-way Speaker, Bass-reflex Type
Frequency range (-10dB) - 48 Hz - 20 kHz
Nominal coverage
- H - 90°
- V - 60°
Components
- LF - 12" Cone, 2" Voice Coil (Ferrite Magnet)
- HF - 1.4" Voice Coil, Compression Driver (Ferrite Magnet)
Crossover - 2.1 kHz
Power rating
NOISE - 175W
PGM - 350W
PEAK - 700W
Nominal impedance - 8O
SPL
Sensitivity (1W; 1m on axis) - 96dB SPL
Peak (Calculated) - 125 dB SPL
I/O connectors - 1/4" Phone x 1, speakON NL4MP x 1
Cabinet material - Plastic
Finish - Black
Handle - Side x 2
Flying and mounting hardware - Bottom x 2, Rear x 1 (Fit for M8 x 15mm Eyebolts)
Pole socket - F35 mm Bottom x 1
Dimensions
W - 376mm (14.8")
H - 601mm (23.7")
D - 348mm (13.7")
Net weight - 13.9 kg (30.6 lbs)
Accessories - Optional Speaker Bracket: BBS251, BCS251, BWS251-300, BWS251-400
