Features

• Classic Look
• Extended Range Gathering
• Deeper Range Activity
• Patent Housing
• New Auto-clean

Double Cavities
Double Cavities, Double Negative Pressure Zones, Most Efficient Suction

Turbo Suction
Turbo function for Wok and Deep-fry. Turbo Suction: 22. Normal Suction: 20

Patent Smoke Exhaust Technology
450Pa Powerful Negative Pressure Zone. Exhausting Smoke Before Escaping

Patent V Shape Motor Housing
Better Performance for More Fluent Smoke Removal

Specification

• Rating Voltage & Frequency:220V-240V/50Hz
• Max Static Pressure:450 Pa
• Rating Motor Power:270 W
• Rating Illumination Power:5W
• Rating Pump Power:12V=/12W
• Suction Volume:22m^3/min
• Turbo Suction Volume:20m^3/min
• Noise Level:53dB
• Odor Reduce Rate (Normal):95%
• Oil Separation Degree: 85%
• Duct Size:φ190mm
• Product Dimension/(with hood corner gasket):896*510*615mm
• Chimney Dimension/(with hood corner gasket):400*324()*400mm
